Low - intensity Obstruction Light Controller with Photocell and Alarm Function
Product Details
| Type Name: | Low-intensity LED Aviation Obstruction Lights Controller | Control Capacity For Aviation Lights: | ≤6 |
|---|---|---|---|
| Operating Voltage: | AC220V (Option Other Voltage, AC120V, DC48V, DC24V, Etc) | Protection Standard: | IP67 |
| Enclosure Material: | Die Casting Aluminum | Max Load: | 2KW |
| Ambient Temperature: | -55℃~+70℃ | Power Consumption: | 10W |
| Highlight |
tower obstruction lighting,led aircraft warning lights |
||
Product Description
Low - intensity Obstruction Light Controller with Photocell and Alarm Function
Product Descripton
| Description | Parameter |
|---|---|
| Mode | AH-OC |
| International Standard | ICAO Annex 14 |
| Control capacity for Aviation Obstruction Lights | ≤6 |
| Supply voltage | AC220V (Option other voltage, AC120V, DC48V, DC24V, etc) |
| Power | 10W |
| Max load | 2KW |
| Enclosure material | die casting aluminum |
| Working way | at night or all day |
| Application lights | Low-intensity Single and Double Aviation Obstruction Light |
| Light Intensity | 2,000cd ±25% |
| Ambient temperature | -55℃~+70℃ |
| Protection standard | IP67 |
| Net Weight | 1.50kg |
Product Application area
High-rise Building, High Chimney, marking towers (Telecom, GSM, Microwave & TV),High Pole,Tower Crane, Wind Tubinebridge.large-scale port machinery,large engineer machinery and wind turbines.
Packaging & Delivery time
Packaging: Plastic bag with paper carton.
Delivery: In 15 days after payment.
Dimension Drawing
Product Picture
Product Highlights
