Advantages
1.Visual range 2 Nautical Miles (Tc =0.74)
2.Based on LED technology and its color comply to IALA Recommendations E-200-1.
3.Bird spike against bird nesting.
4.Comprehensive protection in short ciruit-voltage,overload-voltage,floating charge and temperature.
5.International-advanced cold and special LED with low power consumption, high brightness and service life of light source reaching 100000hours.
6.Strong anticorrosion ,Rain and Snow,seismic resistance protection and UV protection.
7.Clean, renewable, green and reliable energy source.
8.Dusk-to-dawn operation: photocell. Light can work at night automatically by photocell.
9.More than 5 days autonomy without sunshine (Option 20days).
10.Recyclable batteries with the lightest environmental.
11.IP68 protection standard, Full sealing structure.
SPECIFICATIONS | AH-LS/C Solar Marine Navigation Lantern |
Light Characteristics | |
Light Source | LED |
Available Colors | Red, Green, White, Yellow |
Visible Range(NM) | AT@0.74: 1-2 |
Horizontal Output(degrees) | 360 |
Vertical Divergence(degrees) | 7 |
Flash Characteristics | Steady & Flashing adjustable |
Operation Mode | Dusk-to-dawn Automatically(Built-in photocell) |
LED Life-span Experience(hours) | >100,000 |
Electrical Characteristics | |
Operating Voltage | 3.7 |
Power consumption(W) | 0.55 |
Circuit Protection | Integrated |
Solar Characteristics | |
Solar Module Type | Monocrystalline Silicon |
Output(watts) | 0.55 |
Charging Regulation | Microprocessor controlled |
Battery Characteristics | |
Battery type | Lithium ion battery |
Battery Capacity (Ah) | |
Nominal Voltage (V) | 3.7 |
Battery Service Life | Average 3 years |
Autonomy (hours) | Steady: 60 |
Flashing: 150 | |
Physical Characteristics | |
Body Material | UV protected Polycarbonate |
Base Material | Powder-coated Die-casting aluminum |
Mounting | 140×140×M6 |
Dimension(mm) | 162×162×160 |
Mass(kg) | 1 |
Product Life Expectancy | Average 5 years |
Environmental Factors | |
Humidity | 0~100% |
Wind Speed | 80m/s |
IP rate | IP68 |
Compliance | |
IALA | Singal colors complicant to IALA E-200-1 |
Options Available | Charging port |
Remote Control | |
Flashing rate | |
Auto/Manual toggle switch |
