Quality FATO TLOF Solar Taxiway Edge Light Portable Aiming Point factory
Quality FATO TLOF Solar Taxiway Edge Light Portable Aiming Point factory
>

FATO TLOF Solar Taxiway Edge Light Portable Aiming Point

Brand Name: ANNHUNG
Model Number: AH-SA-B
Place of Origin: China
Certification: CE
Minimum Order Quantity: 1

Product Details


Light Source: LED Available Colors: Red, Green, Yellow, White, Blue
Horizontal Output(degrees): 360 Vertical Divergence(degrees): ≥8
Flash Characteristics: Steady(Flashing Mode Is Optional) Operation Mode: 24hours Working After Switched ON
Highlight

FATO Taxiway Edge Light

,

TLOF Taxiway Edge Light

,

Aiming Point Runway Edge Lighting

Product Description

FATO TLOF Solar Taxiway Edge Light Portable Aiming Point



AH-SA-B Solar Airfield Light



AH-SA-B Solar Airfield Light is specially used on permanent airport/heliport where cable power is not convenient or temporary helipad. Light weight make it very easy for user to take and move the AH-SA-B.



Fragile coupling need to be paid separately if needed.



Compliance

ICAO Annex 14 Volume ǁ Heliports 5.3.

FAA AC 150/5390-2B Heliport Design Guide

CAP 437



Features

Electrical

LED as light source saving power consumption and maintenance, 95% less power than equivalent incandescent light



Physical

Integrated design, enabling a rugged and completely waterproof seal capable of prolonged and deep immersion (IP68).

PC housing,UV resistance, shockproof and corrosion proof.

Bird deterrent spike

Powder coated die casting aluminum base

Built-in mono crystalline silicon solar panel, conversion efficiency is better than poly crystalline silicon



System design

ON/OFF button interface located under base



Optional

External battery charger for 110-240vac charging

Wireless remote control

Carry case for batch of lights

NVG - compatible infrared (IR) LED

Installation bracket



Application

Airport, Touchdown and Lift- off area ( TLOF) , Final Approach and Take- off area ( FATO) , Taxiway lighting, Runway edge lighting, Portable or expedited airfield lighting, Threshold lighting

Helipad taxiway

Emergency operations



FATO TLOF Solar Taxiway Edge Light Portable Aiming Point

Product Highlights

FATO TLOF Solar Taxiway Edge Light Portable Aiming Point AH-SA-B Solar Airfield Light AH-SA-B Solar Airfield Light is specially used on permanent airport/heliport where cable power is not convenient or temporary helipad. Light weight make it very easy for user to take and move the AH-SA-B. Fragile ...
