AH-HP-R2 Airport Rotating Beacon
The heliport/Airport beacon shall be located on or adjacent to the heliport preferably at an elevated position and so that it does not dazzle a pilot at short range.
This Rotated beacons is for night operation as identification and location markers for airports.
Compliance
FAA L-801, L-802 150/5345-12F
ICAO Annex 14 Volume I 5.3.3
Features
LED as light source, ≥100,000 hour typical lamp life.
Two head, Two emitting color
No maintenance
Weatherproof stainless steel cabinet, powder-coated international aviation yellow.
Solar power system is optional, ensure the lights could be used at area without electrical power supply
Application
Helipad/Heliport/Helideck
Airport
| Description |
Parameter |
| Light Source |
LED |
| Flash Characteristics |
24 flashes per minute
|
| Operation Mode |
24hours operation
|
| LED Life Experience(hours) |
>100,000 |
| Operating Voltage |
220/240AC
|
|
Circuit Protection
|
Integrated
|
| Mounting |
390×70×θ12
|
| Dimension(mm) |
566×260×740
|
| Weight(kg) |
22 |
| Ambient Temperature(℃) |
-40~65
|
| Humidity |
10~90%
|
| Wind Speed |
80m/s
|
| Waterproof |
IP66 |
| Options Available |
Solar power system
|
