Airfield Solar Helipad Taxiway Edge Light LED Steady AH-HP-RC Contoller
Product Details
| Light Source: | LED | Available Colors: | Blue |
|---|---|---|---|
| Flash Characteristics: | Steady(Flashing Mode Is Optional) | Operation Mode: | Controlled By AH-HP-RC Contoller |
| Installation Size: | 200×200×M10 | Overall Size (mm): | 250×250×250 |
| Highlight |
solar helipad Taxiway Edge Light,AH-HP-RC contoller Solar Airport Lighting,Airfield Solar Taxiway Edge Light |
||
Product Description
AH-SA-A-TE-B Taxiway Edge Light
Compliance
CAO Annex 14 Vol. I (7th. Edition, July 2016)
Features
Physical
4-side mono crystalline silicon solar panel, conversion efficiency is better than poly crystalline silicon
Electrical
LED as light source saving power consumption and maintenance, 95% less power than equivalent incandescent light
System design
ON/OFF button interface
Remote Controlled By wireless remote controller
Application
Taxiway lighting
Optional
External battery charger(110-240VAC)
GPS sync flashing
| Description | Parameter |
| Light Source | LED |
| Flash Characteristics |
Steady burning |
| Operation Mode |
24hours operation |
| LED Life Experience(hours) | >100,000 |
|
Battery type
|
Lithium ion battery
|
|
Solar Module Type
|
Mono crystalline Silicon
|
| Mounting |
200×200×M10
|
|
Dimension(mm) |
250×250×250
|
|
Weight(kg) |
5 |
|
Ambient Temperature(℃) |
-55~70 |
| Humidity |
0~100% |
| Wind Speed |
80m/s |
| Waterproof | IP68 |
|
Options Available |
Frangible coupling base
|
