Heliport Inset light is always be installed at locations where the lights are frequently knocked down by aircraft or maintenance vehicles.
A TLOF lighting system shall be provided at a heliport intended for use at night. TLOF perimeter lights shall be placed along the edge of the area designated for use as the TLOF or within a distance of 1.5 m from the edge.
The TLOF perimeter lights shall be fixed omnidirectional lights showing green.
8inch International standard mounting for aerodrome inset light.
Compliance
l FAA AC 150/5390-2B Heliport Design Guide
l CAAC MH 5001—2013 Aerodrome technical standards
l CAAC MH 5013—2014 Technical Standards of Civil Heliports
Features
Electrical
l Ultra high intensity CREE LED as light source saving power consumption and maintenance, 95% less power than equivalent incandescent light
l Power supply available in AC(110-240VAC), DC48V
Physical
l Pressure resistance lens allowed the vehicles go through on light
l Die-casting aluminum covered by color powder coasted which have good corrosion protection and load bearing.
l IP68 waterproof ensure light work fine underground
Optional
l Infrared LED for pilot using NVG(Night Vision Goggles)
l Controller for power supplying and turn ON/OFF light
l VHF pilot to ground remote control
l Light intensity adjustable
Application
l Surface-level heliport
l Elevated heliport or helideck
| SPECIFICATIONS |
AH-HP-I-TLOF(L) LED Heliport Touchdown and Lift-off Area Lighting |
| Light Characteristics |
|
| Light Source |
CREE Ultra high intensity LED |
| Emitting Color |
Green |
| Intensity(cd) |
ICAO standard, refer to Photometric table |
| Horizontal Degree(°) |
Omnidirection (360°) |
| Vertical Degree(°) |
ICAO specification |
| Flash Characteristics |
Steady burning |
| Operation Mode |
24hours operation |
| LED Life Experience(hours) |
>100,000 |
| Electrical Characteristics |
|
| Operating Voltage |
110-240VAC, 48VDC, 24VDC or others |
| Power(W) |
≤5W |
| Physical Characteristics |
|
| Body Material |
Die-casting aluminum |
| Overall size(mm) |
Θ220×133.47 |
| Installation size(mm) |
Θ225×145-M10*2 |
| Weight(kg) |
4 |
| Product Life Expectancy |
≥10 years
|
| Environmental Factors |
|
|
Ambient Temperature(℃)
-55℃~+70℃
|
-55~70 |
| Humidity |
0~100% |
| Waterproof |
IP68 |
| Compliance |
|
| |
|
| Options Available |
|
| |
Infrared LED compatible for NVG (Night |
| |
Vision Goggles) |
| |
Light intensity adjustable |
| |
VHF pilot to ground remote control
|
