12VDC TLOF Helipad LED Solar Approach Light For Airport
Product Details
| Light Source: | Super Bright Long Life Light-emitting Diode (LED) | Ip Rating: | IP66 |
|---|---|---|---|
| Lamp Body Material: | Aluminum Alloy, Polycarbonate | Input Voltage(v): | 12VDC |
| Working Mode: | Steady Burning | Emitting Color: | White Color |
| Product Name: | LED Solar Powered Approach Light White Solar Aiport Lighting Runway Light Helipad Approach Lighting | Type: | Solar Airport Light, Approach Light |
| Highlight |
Helipad LED Solar Approach Light,TLOF LED Solar Approach Light,12VDC Solar Runway Light |
||
Product Description
LED Solar Powered Approach Light White Solar Aiport Lighting Runway Light Helipad Approach lighting
AH-SA-S1 LED Solar Powered Approach Light use unidirectional optics, designed for permanent usage at Non-Precision Runways located in regions without access to electricity and high photovoltaic potential.
Solar power system is equipped for operating 365 days on solar energy.
Application
Airport, Touchdown and Lift- off area ( TLOF) , Final Approach and Take- off area ( FATO) , Taxiway lighting, Runway edge lighting, Portable or expedited airfield lighting, Threshold lighting, Runway end light
Helipad taxiway
Emergency operations
Airport/Airdrome
Compliance
ICAO Annex 14 Vol. I (7th. Edition, July 2016)
CAP 437
Features
Electrical
LED as light source saving power consumption and maintenance, 95% less power than equivalent incandescent light
Physical
Integrated design, enabling a rugged and completely waterproof seal capable of prolonged and deep immersion (IP67).
PC housing, UV resistance, shockproof and corrosion proof.
Powder coated die casting aluminum base
System design
ON/OFF button interface
Wireless remote control by AH-HP-RC
Optional
External battery charger
NVG - compatible infrared (IR) LED
Pilot to ground remote control(VHF radio control)
| SPECIFICATIONS | AH-SA-S1 LED Solar Powered Approach Light |
| Light Characteristics | |
| Light Source | LED |
| Available Colors | White |
| Intensity(cd) | 90(L1), 360(L2), 1200(L3), 5500(L4), 20000(L5) |
| Flash Characteristics | Steady |
| Operation Mode | Wireless remote controlled ON/OFF |
| LED Life Experience(hours) | >100,000 |
| Electrical Characteristics | |
| Operating Voltage | 11.1V |
| Circuit Protection | Integrated |
| Solar Characteristics | |
| Solar Module Type | Mono crystalline Silicon |
| Charging Regulation | Microprocessor controlled |
| Battery Characteristics | |
| Battery type | Lithium ion battery |
| Nominal Voltage (V) | 11.1 |
| Battery Service Life | Average 5 years |
| Physical Characteristics | |
| Lamb Body Material | Polycarbonate |
| Base Material | Powder-coated Die-casting aluminum |
| Installation Size | 140×140×M10 |
| Overall Size (mm) | 560×500×514 |
| Weight(kg) | 10 |
| Product Life Expectancy | Average 10 years |
| Environmental Factors | |
|
Ambient Temperature(℃) -55℃~+70℃ |
-55~70 |
| Humidity | 0~100% |
| Wind Speed | 80m/s |
| Waterproof | IP67 |
| Compliance | |
| ICAO |
ICAO, Annex 14th,Volume I, 7th Edition dated July 2016, clause 5.3.9.9 & Appendix 1, Figure A1-1b clause 5.3.9.9 & Appendix 1, Figure A1-1b
|
| Optional | |
|
External battery charger
|
|
|
NVG - compatible infrared (IR) LED
|
|
| Pilot to ground remote control(VHF radio control) |
Catalog download: Download AH-SA-S1 LED Solar Powered Approach Ligh...
