ICAO Heliport Red Outside Flood Lights Wind Direction Indicator Customized Windsock

ICAO Heliport Wind Cone, Wind Direction Indicator Wind Sock

AH-HP-1S aerodrome shall be equipped with at least one wind cone as wind direction indicator.

The flood light for illumination is inside wind sock, it will rotate together with windsock too.
One obstruction light on top for aircraft warning. Better design for you.

Compliance

  **  ICAO Annex 14 Volume ǁ Heliports 5.1.1
  ** FAA AC 150/5390-2B Heliport Design Guide

Features
 Power supply available in DC(12-48VDC) or AC(110-240VAC)
 Pole is made of corrosion resistance and wind resistance stainless steel 304(SS316 is optional)
 One obstruction light on top, one flood light for illumination
 Pole height is customized(1meter, 2meter, 2.5m, 3m, 4m, 5m...)
 Windsock color is: orange(Nylon), red/white(PVC)
 Windsock dimension:

Pole height: < 4m, Length: 1.2m, big diameter: 300mm, small diameter: 150mm

Pole height: 4-6m, Length: 2.4m, big diameter: 600mm, small diameter: 300mm

Pole height: > 6m, Length: 3.6m, big diameter: 900mm, small diameter: 450mm

Other size is customized

Frangible cuopling is optional

Environmental Factors

Ambient Temperature(℃): -55~70

Humidity: 0-95%

Wind Speed: 80m/s

Waterproof: IP65


Contact us:

Product detailed imagine:

ShenZhen Anhang TechnologyCompany Limited is a specialized enterprise focusing on research, production, sales and after-sales service of helipad lighting.Our factory located in Shenzhen City, China and have more than 8 years manufacturing experience for clients from whole world. Fell free to contact us.
