ICAO Aiming Helicopter Landing Lights Xenon Heliport Beacon Clear Polycarbonate Lens
Product Details
| Horizontal Output(degrees): | 360 | Vertical Divergence(degrees): | ≥10 |
|---|---|---|---|
| Flash Characteristics: | 4 Quick Flashes In 0.8s, Off 1.2s(Morse Code “H”) | Operation Mode: | 24hours Operation |
| LED Life Experience(hours): | >100,000 | Operating Voltage: | 12 |
| Circuit Protection: | Integrated | ||
| Highlight |
perimeter lighting products,helicopter landing lights |
||
Product Description
This AH-MI-B Medium-intensity Type B Aviation Obstacle Light, designed for marking top of obstruction which height is between 45 to 105 meters.Ultra high intensity LED is used as light source which make performance better, and solar panel vertical degree is adjustable(30° ) for get as much as sunlight in different area, suitable many sicuations.
Compliance
ICAO Annex 14 Volume 1, Sixth edition, 2013, table 6.3 Medium Intensity Type B Obstruction Light
FAA L-864
Electrical
Ultra high intensity LED light source saving power consumption and maintenance
Physical
UV & vibrations protected polycarbonate lens for converging light Self-contained without external power supply, Cable cost saving & cabling job saving, No wiring j
System design
Solar panel as photocell for day & night working mode (dusk to dawn mode)
ON/OFF button beside base
Optional
► GPS Synchronization
► Infrared LED for pilot using NVG
Application
AH-MI-B solar medium-intensity light is specialized used on the top of the High Chimney, Telecommunication tower, Wind Turbine
where there is no cable power supply and those facilities which have high requirements on lightning protection, and most time work with low intensity lights light installed on the lower place.
More product parameter:
| Light Source | Ultra high intensity LED |
| Intensity(cd) | 2000cd±25%(Night) |
| Solar Module Type | Mono crystalline Silicon |
| Output(watts) | 18 |
| Charging Regulation | Microprocessor controlled |
| Battery type | Lithium ion battery 12V |
| Battery Service Life | Average 3 years |
| Autonomy (hours) | 120 |
| Lamb Body Material | UV protected Polycarbonate |
| Base Material | Die casting aluminum |
| Overall Size (mm) | 400×260×325 |
| Installation Size | 190×190×M6 |
| Ambient Temperature(℃) | -35~80 |
| Humidity | 0~95% |
| Wind Speed | 80m/s |
| Waterproof | IP65 |
| ICAO | ICAO Annex 14 Volume ǁ Heliports 5.3.2 |
Online communication:


Delivery:

We will try our best to help every customer also provide professional technical support. If you have any question,feel free to contact me. We have more than 8 years manufacturing experience for clients from whole world
