ICAO Annex 14 Heliport Rotated Beacon
Product Details
| Name: | Helipad Rotating Beacon | Standard: | ICAO Annex 14 |
|---|---|---|---|
| Available Colors: | White And Yellow(others Are Optional) | Flash Characteristics: | 24 Flashes Per Minute |
| Operating Voltage: | 120VAC, 220VAC, | Body Material: | UV Protected Polycarbonate |
| Base Material: | Powder-coated Stainless Steel 304 | ||
| Highlight |
ICAO Annex 14 Landing Lights,Helipad Rotating Beacon |
||
Product Description
Helipad Rotating Beacon Airport Beacon 2-color heliport rotated beacon
The heliport beacon shall be located on or adjacent to the heliport preferably at an elevated position and so that it does not dazzle a pilot at short range.
light video
This Rotated beacons is for night operation as identification and location markers for airports.
Compliance
l FAA L-801A
l ICAO Annex 14 Volume I 5.3.3
Features
l 100,000 hour typical lamp life.
l One white color, another yellow color
l No maintenance
l All moving parts are permanently lubricated.
l Impedance-protected motor eliminates burnouts.
l 12RPM rotation, 24 flashes/minute.
l Weatherproof stainless steel cabinet, powder-coated international yellow.
Application
l Helipad/Heliport/Helideck
l Airport
| SPECIFICATIONS | AH-HP-R2 Airport Rotating Beacon |
| Light Characteristics | |
| Light Source | LED |
| Colors | White and Yellow(others are optional) |
| Flash Characteristics | 24 flashes per minute |
| Light intensity | ≥2500cd |
| Operation Mode | Steady burning |
| LED Life Experience(hours) | >100,000 |
| Electrical Characteristics | |
| Operating Voltage | 220/240AC |
| Circuit Protection | Integrated |
| Physical Characteristics | |
| Body Material | UV protected Polycarbonate |
| Base Material | Powder-coated stainless steel 304 |
| Mounting | 390×70×θ12 |
| Dimension(mm) | 566×260×740 |
| Weight(kg) | 22 |
| Product Life Expectancy |
Average 5 years
|
| Environmental Factors | |
|
Ambient Temperature(℃) -55℃~+70℃ |
-40~85 |
| Humidity | 10~90% |
| Wind Speed | 80m/s |
| Waterproof | IP66 |
| Compliance | |
| FAA | FAA L-801A |
| ICAO |
ICAO Annex 14 Volume I 5.3.3
|
| Options Available |
Datasheet download : AH-HP-R2 Airport Rotating Beacon.pdf
