Cold Led Runway Lights With High Brightness Quake - Proof Protection

Minimum Order Quantity : 1 pc Price : Negotiable
Packaging Details : paper carton 1 piece/box Delivery Time : Shipped in 15 days after payment
Payment Terms : T/T, Western Union, MoneyGram Supply Ability : 1000 pcs per month
Place of Origin: Guangdong, China Brand Name: Anhang
Certification: ICAO Model Number: AH-SA/B

Detail Information

Light Intensity: ≥10cd Working Mode: Steady-burning Mode Or Flash Mode
Light Source: LED Net Weight: 1 Kg
Emitting Color: Red, Green, White, Yellow/ White, Yellow/ White, Yellow/ White, Red/ White( Customized) Protection Standard: IP68
High Light:

airport led lighting

,

solar runway lights

Product Description



Cold Led Runway Lights With High Brightness Quake - Proof Protection





Advantage



1.International advanced solar panel reaching more than 10 years service life.
2. Easy installation and relocation: no specialized work crew required, limited air traffic disruption, and lights are    immediately operational .
3. Comprehensive protection in voltage short circuit, over-voltage, floating charge and over temperature.
4. Built-in Solar Panel.
5. Self-contained and low maintenance: all components are incorporated within a compact, stand-alone unit.
6. Strong anticorrosion , Rain and Snow, quake-proof protection and UV protection.
7. International-advanced cold LED with low power consumption, high brightness and service life of light source reaching 100000hours.
8. Clean, renewable, green and reliable energy source.
9. Dusk-to-dawn operation: Built-in photocell inside light can let lightwork at night and close during    the day automatically.

10. More than 5 days autonomy.
11. Recyclable batteries with the lightest environmental.



Main Parameter



1.Mode: AH-SA/ B
2.Light intensity: ≥10cd
3.Working mode: Steady-burning mode or Flash mode
4.Light source: LED,100,000hours service life
5.Solar panel: DC3.7V,monocrystalline silicon
6. Material: -Housing: Polycarbonate
-Base: die casting aluminum
7.Autonomy(without sunlight): at least 5 days(Option 20days)
8.Battery: Lithium ion battery, replaceable
9.Overall Size(mm): 162 by 162 by 160
10.Installation Size(mm): 140 by140 by M6
11.Weight: 1Kg
12.Emitting Color: Red, green, white, yellow/ white, yellow/ white, yellow/ white, red/ white( Customized)
13.Ambient Temperature: -40℃~+60℃
14.Wind load: 80m/s
15. Protection Standard: IP68
16. Optional: charging port


Function



1.Push button interface for local ON/OFF control. Toggle switch interface for steady-burning/flashing working    mode.
2. Optional Battery Charge port: 100~240VAC
3. Optional NVG-compatible infrared (IR) LEDs



Application



Emergency operations, Helipads, Touchdown and Lift- off area ( TLOF) , Final Approach and Take- off area ( FATO) , Taxiway lighting, Runway edge lighting – (ICAO Annex 14), Portable or expedited airfield lighting, Threshold lighting and obstruction lighting.



Dimension Drawing



Cold Led Runway Lights With High Brightness Quake - Proof Protection 0





Product Picture



Cold Led Runway Lights With High Brightness Quake - Proof Protection 1



Cold Led Runway Lights With High Brightness Quake - Proof Protection 2
