Red Medium Intensity Obstruction Light / Aircraft Warning Light
  • Red Medium Intensity Obstruction Light / Aircraft Warning Light
  • Red Medium Intensity Obstruction Light / Aircraft Warning Light

Red Medium Intensity Obstruction Light / Aircraft Warning Light

Place of Origin Shenzhen, China
Brand Name ANNHUNG
Certification ICAO
Model Number AH-MI/I
Product Details
Light Source:
LED
Emitting Color:
Red
Wind Load:
80m/s
Protection Standard:
IP67
Weight:
5KG
Service Life Of LED:
≥ 100,000hours
High Light:

led warning lights

,

waterproof outdoor lights

Payment & Shipping Terms
Minimum Order Quantity
1 pc
Price
Negotiable
Packaging Details
paper carton 1 piece/box
Delivery Time
Shipped in 15 days after payment
Payment Terms
T/T, Western Union, MoneyGram
Supply Ability
1000 Pieces Per Month
Product Description



Red Medium Intensity Obstruction Light / Aircraft Warning Light





Advantages



1.Stand alone design with integrated photocell, power supply flasher and monitoring
2.Integrated automatic flash synchronisation beam optical design
3.High borosilicate glass material with good thermal stability, high transmittance.
4.Built-in circuit protect LED, extremely reliable and cost saving.
5.Shockproof and corrosion resistant. It can be used in very poor conditions.
6.LED is special red color for Aviation Obstruction Light. Typical LED lifetime is more than 100,000 hours.
7.Resistant to heavy rain or storms.
8.Free maintenance and aluminum alloy Material.
9.Five year warranty
10.low power consumption and low cost of ownership.



Detail Description:



This product is double light with Photocell. It can work at night and close during the day automatically. There are two lights. One works, the other is for standby. When main light is broken, standby light can work automatically.



Application:



Red Medium Intensity Obstruction Light / Aircraft Warning Light 0



This series of products can be used alone on the top of the High-rise Building, High Chimney, marking towers (Telecom, GSM, Microwave & TV),High Pole, Tower Crane, Wind Tubine, etc whose height is
between 45m and 105m. When the building is higher than 105m, this series of products can be used with Medium-intensity Type A or highintensity obstruction light to potentially hazardous obstructions to air
traffic flashing red safety light.



Specifications:



SPECIFICATIONS AH- MI/I Medium-intensity Double Aviation Obstruction Light
Light Characteristics
Light Source LED
Available Colors Red
Intensity(cd) 2,000cd ±25%
Horizontal Output(degrees) 360
Vertical Divergence(degrees) 3
Reflector Type Fresnel Lens
Flash Characteristics Flashing mode (20 to 60 times/minute)
Operation Mode Dusk-to-dawn Automatically as standard.
LED Life Experience(hours) ≥100,000
Electrical Characteristics
Operating Voltage

AC220V (option

voltage,eg.AC120V,AC110V,DC48V)

Power(W) 60
Circuit Protection Integrated
Temperature Range(℃) -40~60
Physical Characteristics
Body Material High borosilicate glass
Base Material die casting aluminum
Mounting Φ190 by 12
Height(mm) 236
Width(mm) 236
Depth(mm) 245
Mass(kg) 7
Product Life Expectancy 5 years plus
Environmental Factors
Humidity 0~100%
Wind Speed 80m/s
Waterproof IP68
Compliance
ICAO

Medium-intensity Type B, ICAO Annex 14

Volume 1,'Aerodrome Design and

Operations’ Forth edition July

2004,table6.3

FAA

Medium-intensity Type B and FAA L-864 &

L-865





Dimension Drawing



Red Medium Intensity Obstruction Light / Aircraft Warning Light 1





Product Picture





Red Medium Intensity Obstruction Light / Aircraft Warning Light 2





Red Medium Intensity Obstruction Light / Aircraft Warning Light 3
